URD Mk3 Supercharger kit 2016-2023 Tacoma V6, Stage 1

$6499.00

-

Availability: 1 in stock

This kit version ships with the ECU Flash device to load the URD calibration file. You may need to have your ECU flashed with the most current Toyota ECU calibration before we can load our ECU calibration file.  Full details will be provided to you once the order is placed.

URD is pleased to announce our latest supercharger system.  This Stage 1 system is for the 2016 and later Tacoma V6 with the 3.5L V6 Engine.  Other power stages are still in development.

Key Features

  • Rotrex C38 series supercharger
  • Silent operation
  • Turbo style blow off valve
  • Large air-air intercooler
  • Outstanding fit and finish
  • Easy installation
  • Off road snorkel compatible
  • Off road winch bumper friendly



Kit includes

  • Rotrex C38 Series Supercharger
  • Self contained Rotrex oil system with large oil cooler
  • Precision charge piping made from mandrel bent aluminum
  • All stainless fasteners where possible
  • All silicone couplers with quality stainless liner clamps
  • HKS SSQV turbo style blow off valve
  • Drive belt idler pulleys
  • URD supercharger mounting bracket
  • URD custom air filler box with large panel type filter
  • Very detailed installation instructions



URD has chosen the highly efficient Rotrex C38 series supercharger as the center of this supercharger system. The Rotrex is most advanced supercharger design on the market today. It features a small compact foot print with almost completely silent operation, with a very highly efficient traction roller drive system that will spin the turbo type impeller 7.5 times faster than the belt drive pulley is turned. This high step up ratio and small diameter turbo style impeller brings boost in sooner than other more common types of centrifugal superchargers. This gives you very nice off the line performance combined with unmatched top end power. The Rotrex Supercharger features it own self contained oiling system using Rotrex’s proprietary traction oil that is the key to the advanced traction drive system. Rotrex warranties their superchargers with an industry leading one year UNLIMITED mileage warranty.  A Rotrex 3 year warranty on the supercharger can be purchased at extra cost.

The air intake system brings in cool air from the stock location in the fender wall and into a custom air filter box which is CAD designed and flow optimized. This configuration makes it compatible with off road snorkel systems.

The overall operation of the supercharger system is nearly completely silent, but we have added a turbo style blow off valve will announce that your Tacoma indeed boosted. When the throttle is suddenly closed when the engine is at high RPM like shifting gears with boost, the blow off valve will cycle with a very crisp note typical of high performance turbo systems. It is always a crowd pleaser!!

The kit includes all the needed brackets, parts, and fasteners to allow a trouble free, no hassle installation. We include high quality stainless fasteners where possible, and all the parts have a high quality wrinkle black powder coating finish that will last and looks fantastic. The piping is all mandrel bent high quality aluminum they fit like they are supposed to. Only the best in kit components are used.

The installation on your Tacoma straight forward and the only modification to the vehicle require is some slight trimming of the radiator core support to pass the charge pipes through. No part of the kit runs under the truck or frame.

We made every effort to make the system compatible with off road winch bumpers. We cannot guarantee compatibility with all bumpers on the market, but several of our V6 kits have not had any problems with the different winch bumpers on the market.

URD has worked very hard to bring you the finest supercharger kit for your Tacoma and we are very sure you will be very happy with it!!

This supercharger system is not CARB exempt or approved.  Legal in California Only for Racing Vehicles Which May Never be Used on a Highway

Specifications, components, pricing, and availability subject to change.

Year Make Model Engine
Year Make Model Engine
2016 - 2023 Toyota Tacoma V6 3.5L 2GR-FKS
Weight 86 lbs
Dimensions 36.5 × 24.5 × 12.5 in
